BIO-UV Integra
The BIO-UV Integra range has been designed to treat high-quality fresh or seawater (85-98 % UVT). Its electropolished stainless-steel reactor and medium-pressure lamps allow it to operate in cold, temperate, or very hot applications.
Benefits +
- Suitable for onshore and offshore installations: flexible use across diverse environments
- Algae growth reduction: improves water quality and stability
- Savings on water, energy, and chemicals: a sustainable and cost-effective solution
- Marine-approved electrical cabinet: reliability and compliance for maritime applications
- Low investment (CAPEX) and installation costs: optimised financial resources with minimal service space required
- Suitable for both indoor and outdoor applications: versatile integration
- Exceptional corrosion resistance: extended lifespan in demanding environments
- Built-in UV sensor: continuous performance monitoring
Certification
NVI (Norwegian Veterinary Institute)
The UV Integra solution is NVI-certified by the Norwegian Veterinary Institute, ensuring its reliability and effectiveness in water treatment. This certification, recognised in several European countries, confirms that our system meets strict safety and performance standards for industrial and aquaculture applications.
Technical data
| Model | Max. flow rate* | Delivered UV doses at indicated UVT / Flow rate** | UV lamp power | Connection | Reactor length |
| Integra 125 | 38 m3/h | 40 mJ/cm2 | 1 x 1.8 kW | DN125 | 510 mm |
| Integra 150 | 275 m3/h | 40 mJ/cm2 | 2 x 2.5 kW | DN250 | 645 mm |
| Integra 250 | 460 m3/h | 40 mJ/cm2 | 4 x 2.5 kW | DN300 | 734 mm |
| Integra 300 | 635 m3/h | 40 mJ/cm2 | 4 x 3.7 kW | DN300 | 800 mm |
| Integra 500 | 1730 m3/h | 40 mJ/cm2 | 6 x 3 kW | DN500 | 870 mm |
| Integra 1000 | 3200 m3/h | 40 mJ/cm2 | 6 x 6 kW | DN500 | 870 mm |
| Integra 1500 | 3175 m3/h | 40 mJ/cm2 | 8 x 6 kW | DN600 | 944 mm |
| Integra 2000 | 4300 m3/h | 40 mJ/cm2 | 8 x 7 kW | DN700 | 1151 mm |
| Integra 3000 | 7530 m3/h | 40 mJ/cm2 | 8 x 8,8 kW | DN900 | 1371 mm |
| Integra 4000 | 8000 m3/h | 40 mJ/cm2 | 12 x 8,8 kW | DN700 | 1361 mm |
* For different flow rates, contact us. ** The performance of these devices was calculated at the lamp end-of-life and with 98% transmittance.
